The backbone of your building starts here.
Our Beam and Column Layout – Framing Service provides a detailed structural framework that defines the placement, orientation, and size of key structural components.
This drawing ensures your building’s load-bearing elements are positioned correctly as per the architectural plan.
Deliverables:
Column grid plan
Beam direction and connectivity
Centerline drawings
Foundation and slab reference details
Perfect for early-stage planning, this layout helps contractors and engineers coordinate effectively during structural execution.
